434.50MHz Radio Transmitter module with crystal oscillator, FSK Modulation

Power down mode is available.

     datasheet.jpg                     Catalog.jpg

In stock
7,00 €
Tasse escluse

La quantità minima ordinabile per questo prodotto è 2.

Quantità Sconto unità Salva
20 20% 28,00 €


434.50MHz FSK Radio Transmitter Module

 RC-TXFSK-434.5 is an FSK Radio tranmitter module with crystal oscillator, dual line package operating at 3.3Volt. Output power 10dBm. Power down mode is also available.



(*)we recommend the use of an antenna with a gain not higher than 3dB
Technical Characteristics MIN TYP MAX UNIT
Supply Voltage   2.2    3.6 Volt
 Current Consumption (TX Mode)    21 / 15    mA
 Current Consumption (Standby mode)    <3  100  µA
 Frequency    434.5    MHz
 RF Output Power      10(*) dBm
 Frequency Tolerance   ±20      KHz
 Max data rate    50    Kbit/s
 Power Up Timer      1 ms
 Operating Temperature range -25   +80 °C



Pads  Name  Description
 1  EN  Enable
 2  DATA IN  Data Input
 3  GND  Ground
 4  VCC Power Supply
 5  GND  Ground
 6  ANT  Antenna
Frequenza
434.50MHz
Tipo di Modulazione
FSK
Tensione di Alimentazione
2.2 - 3.6 Volt
Assorbimento
21/15mA
Conformità
CE RED
Potenza RF
10dBm
