RC-RXASK-434.15
8,00 €
Tasse escluse
RC-RXASK-434.15 is an AM Radio Receiver module with PLL synthesizer and crystal oscillator, single line package operating at 5Volt with power down mode.
Frequency : 434.15MHz
On request, it is possible to realize a receiver with a specific frequency in the following ranges:
- from 433.00MHz to 435.00MHz with 0.01 MHz steps.
- from 867.00MHz to 870.00MHz with 0.01MHz steps.
It's possible to make samples immediately.
Standard versions available:
- RC-RXASK-433 ===> Frequency 433.92MHz
- RC-RXASK-868 ===> Frequency 868.35MHz
Custom versions already available:
- RC-RXASK-433.42 ===> Frequency 433.42MHz
- RC-RXASK-434.15 ===> Frequenza 434.15MHz
- RC-RXASK-434.50 ===> Frequency 434.50MHz
- RC-RXASK-868.95 ===> Frequency 868.95MHz
- RC-RXASK-869.50 ===> Frequenza 869.50MHz
 |
 |
Sicurezza del pagamento (direttamente su PayPal.com)
Consegna entro 3 giorni lavorativi
Cambio e Reso accettato (contattaci per approfondimenti)
RC-RXASK-434.15 is an AM Radio Receiver module with PLL synthesizer and crystal oscillator, single line package operating at 5Volt with power down mode.
| Technical Characteristics | MIN | TYP | MAX | UNIT |
| Supply Voltage | 4.50 | 5.5 | Volt | |
| Frequency | 434.15 | MHz | ||
| Current Consumption (RX Mode 5.0 Volt) | 5.0 | mA | ||
| Current Consumption (Shut Down Mode) | 0,01 | µA | ||
| RF Sensitivity | -110 | dBm | ||
| Max Data Rate | 10 | Kbit/s | ||
| Power Up Timer from Power to stable data | 4 | msec | ||
| Power Up Timer from EN to stable data | 3 | msec | ||
| RF Bandwidt 3dBm | ±350 | KHz | ||
| Operating Temperature Range | -20 | +80 | °C |
8 Articoli
Scheda tecnica
- Frequenza
- 434.15MHz
- Tipo di Modulazione
- ASK (AM)
- Tensione di Alimentazione
- 4.5 - 5.5 Volt
- Assorbimento
- 5.0mA
- Dimensioni meccaniche
- 38.1 x 14.4mm
- Sensibilità
- -110dBm
